WA-5000

NITTO KOHKI WA-5000 Semi-Automatic Drill 115V - 2" x 3" hole capacity

$2,895.00
Sale price  $2,895.00 Regular price

WA-5000 Nitto Kohki Simi-Automatic Mag-Based Drill

Standard Features

    2" x 3 " hole drilling capacity automatic feed with slow startmechanism Step feed feature optimizes cutterpenetration Load detection system monitors andregulates motor speed and cutting feed Powerful 1150 watt doubleinsulated motor Overload stop detection systemhelps prevent motor and cutter damage Load detection system monitors andregulates motor speed and cutting feed Sealed arbor system with throughspindle coolant Built-in motion detection system One touch arbor system No tools required for cutterinstallation and removal Accepts carbide tipped and HighSpeed annular cutters Precision machined die castaluminum mainframe, motor slide and arbor support bracket One year limited warranty

Specifications

Power Source
(Single Phase)
110-120V AC
50/60 hzRated Power Consumption1,150 WRated Current10.8 ANo Load Speed350/650 RPMMagnet Power Consumption75 WHole Diameter2" MaxDepth of Cut3" MaxMagnet Holding Power2,200 lbsMagnet Dimensions4" x 8"Weight51 lbs

Standard Accessories

    2" Pilot pin Hex Keys 8 x 10 mm combination wrench Chip guard assembly Motor side handle Sample cutting fluid Safety chain Carrying case
