V5160PT03XB

ROLAIR V5160PT03XB Single Stage, Three Cast-Iron Cylinders,5 HP, 16 CFM, 3450 RPM, 60 Hz, Single Phase 230V

$1,749.00
Sale price  $1,749.00 Regular price
Skip to product information
V5160PT03XB

ROLAIR V5160PT03XB Single Stage, Three Cast-Iron Cylinders,5 HP, 16 CFM, 3450 RPM, 60 Hz, Single Phase 230V

$1,749.00
Sale price  $1,749.00 Regular price

Electric Stationary Compressor

Features

Pumpdescription

SingleStage, Three Cast-Iron Cylinders, Aluminum Heads for Faster Heat Dissipation,Ball Bearings, Splash Lubricated, High-Efficiency Reed Valves, Oil Sight Gaugeand Trouble-Free Performance.

Motordescription

3450RPM, 60 Hz, Single Phase 230V, Open Drip-Proof Motor. S-1 rated for continuousduty.

 Standardequipment

PressureSwitch - Start/Stop Operation,110-135 PSI Settings, On/Off Switch, AutomaticUnloading Device for Loadless Starts, Heavy-Duty Shut-Off Valve, PressureGauge, 0-200 PSI in 5 lb. Graduations, Safety Relief Valve - ASME Approved,V-Belt Drive, Intake Filter/Silencer w/Replaceable Element, Totally EnclosedSteel Belt Guard.

OptionalEquipment

MagneticStarter, Automatic Tank Drain, Low Oil Shut Down, Level-Rite Mounts, VibrationPads, Dual Controls, Refrigerant Air Dryer.

Specifications

HORSE POWER

 5 HP

CFM DISPLACED @ 100 PSI

16.0 CFM

CFM DELIVERED @ 100 PSI

16.0 CFM

MOTOR RPM

3450 RPM

PUMP RPM

 1200 RPM

PUMP OIL CAPACITY

24 Ounces

SINGLE OR TWO STAGE

 Single Stage

REED VALVE SYSTEM

 Yes (Standard)

TANK CAPACITY

Unit pictured-60 Gallon

L x W x H

  24 x 20 x 70

DECIBEL RATING

 Unavailable

SHIPPING WEIGHT

Unit pictured-298 lbs.

GALLON

 60 GAL
